Version 6.0 - June 2024

Wide Field Camera 3 Data Handbook

User Support

Please contact the HST Help Desk for assistance. We encourage users to access the new web portal where you can submit your questions directly to the appropriate team of experts.

Website: http://hsthelp.stsci.edu
E-mail: help@stsci.edu

Additional Resources

Information and other resources are available from the WFC3 website:

http://www.stsci.edu/hst/instrumentation/wfc3

Revision History

Version	Date	Editor
6.0	June 2024	Amanda Pagul and Isabel Rivera, et al.
5.0	Sep 2021	Kailash Sahu, et al.
4.0	May 2018	Mario Gennaro, et al.
3.0	January 2016	Susana Deustua, et al.
2.1	May 2011	Abhijith Rajan, et al.
2.0	October 2010	Abhijith Rajan, et al.
1.0	January 2009	Jessica Kim Quijano, Howard Bushouse, and Susana Deustua

Contributors

This document is written and maintained by the WFC3 Team in the Instruments Division of STScI. The WFC3 Team, at the time of this writing, consists of M. Alam, J. Anderson, S. Baggett, V. Bajaj, A. Calamida, F. Dauphin, M. de la Pena, L. Dressel, J. D. Green, K. Huynh, H. Khandrika, B. Kuhn, J. Mack, M. Marinelli, C. Martlin, P. R. McCullough, A. O'Connor, A. Pagul, A. Pidgeon, M. Revalski, I. Rivera, S. Shenoy, D. Som.

Citation

In publications, refer to this document as:

Pagul, A. and Rivera, I., et al., 2024, “WFC3 Data Handbook”, Version 6.0, (Baltimore: STScI).
